Multi Functional Printers MX-M564N
Overview
Equipped with many of the advanced performance features that have made Sharp's colour MFPs so successful, the MX-M564N black & white MFP is perfect for all busy offices. Combining colour network scanning capabilities with powerful print, copy and fax features, the MX-M564N has all the functionality and speed you need to put it at the heart of your office operation. Optional Sharp OSA allows seamless integration with cloud applications developed by Sharp's Technology Partners and an optional Wireless LAN Adaptor enables connection to wireless networks. The 56 ppm MX-M564N supports A3-wide network printing and copying, offers fast scanning via the Reversing Single Pass Feeder, produces superb image quality and has versatile document filing; all supported by industry leading security. Productivity can be boosted further by adding fax functionality, extra security, additional paper capacity and a range of professional finishing options. The optional retractable keyboard makes data entry and emailing quick and simple. And the 7.0" colour LCD touch-screen control panel allows documents to be previwed. IT Administrators will appreciate the Remote Access Interface which enables the control panel to be viewed and operated from across the network, plus Sharp's advanced device management makes it easy to control usage and costs. The Energy Star-certified MX-M564N uses Sharp's latest energy-saving technology. Everything - including consumables, power management and internet architecture - is designed to minimise energy consumption, reduce running costs and support environmental objectives.
Specification
General | |
Engine speed Colour ppm (A4) | - |
Engine speed B/W ppm (A4) | 56 |
Engine speed Colour ppm (A3) | - |
Engine speed B/W ppm (A3) | 26 |
Paper size: Min.-Max. | A5R - A3W |
Paper weight (g/m2) | 55 -300 |
Paper capacity:Std (sheets) | 600 |
Paper capacity: Max. (sheets) | 6,600 |
Warm Up Time (sec.) | 12 |
Memory general min/max (MB) | 3072 - 5120 |
Memory printer min/max (MB) | - |
Harddisk | STD |
Harddisk capacity (GB) | 320 |
Duplex | STD |
Power requirements - rated local AC voltage (Hz) | 220 - 240V, 50/60Hz |
Power consumption (kW) | 1,84 |
Dimensions (mm) | 608 x 690 x 837 |
Weight (Kg) | 65 |
Copier | |
Original paper size (Max.) | A3 |
First copy out time Colour (sec.) | - |
First copy out time B/W (sec.) | 3,7 |
E-sort Std | Y |
E-sort Opt. | - |
Continuous copy (Max. copies) | 999 |
Resolution Scan B/W (dpi) | 600 x 600, 600 x 400, 600 x 300 |
Resolution Scan Colour (dpi) | 600 x 600 |
Resolution Print (dpi) | 600 x 600, 9600 (equivalent) x 600 |
Gradation (equivalent levels) - B/W | 2 |
Gradation (equivalent levels) - Colour | 256 |
Zoom range (%) | 25 - 400 (25 - 200 via RSPF) |
Preset copy ratios | 10 |
Document Feeder | |
Original capacity (sheets) | 100 |
Scanner | |
Network Scanner (Standard / Option) | STD |
Scan method Push scan and Pull scan | Y |
Resolution push scan (dpi) | 100, 200, 300, 400, 600 |
Resolution pull scan (dpi) | 75, 100, 150, 200, 300, 400, 600; 50 - 9600 |
File formats | XPS, TIFF, PDF, PDF/A, encrypted PDF, JPEG |
Scanner utilities | Sharpdesk, Sharpdesk Mobile |
Scan destinations Desktop | Y |
Scan destination FTP, Email | Y |
Scan destination Network folder | Y |
Scan destination USB memory | Y |
Document Filing | |
Document filing (Standard / Option) | STD |
Document filing capacity- main and custom folders (pages) | 20.000 |
Document filing capacity - quick file folder (pages) | 10.000 |
Stored jobs | Copy, print, scan, fax transmission |
Storage folders | Quick file folder, main folder, custom folder (max. 1000) |
Confidential storage | Y |
Printer | |
Resolution (dpi) | 600 x 600, 9600 (equivalent) x 600 |
Enhanced resolution (dpi) | 600 x 600 |
Network Printer (Standard / Option) | STD |
Interface Std/Opt | STD USB 1.1, 2.0, 10Base-T/100Base-TX/1000Base-T |
Supported OS Standard | Windows Server 2003, 2008, 2008R2, 2012, Windows XP, Windows Vista, Windows 7, 8 |
Supported OS Options | Mac OS X 10.4, 10.5, 10.6, 10.7, 10.8, 10.9 |
Network protocols | TCP/IP (IPv4,IPv6), IPX/SPX (NetWare), EtherTalk (AppleTalk) |
Printing protocols | LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP, Novell Printserver application with NDS and Bindery, FTP for downloading print files, EtherTalk printing, IPP |
PDL Std/Opt | STD PCL6 emulation. OPT PS3 emulation, XPS |
Available fonts | 80 (PCL), 139 (PS3) |
Fax | |
Fax (Standard / Option) | OPT |
Compression method | MH/MR/MMR/JBIG |
Communication protocol | Super G3/G3 |
Transmission time (sec) | 3 |
Modem Speed (bps) | 33.600 - 2.400 |
Transmission resolution | 203,2 x 97,8, 406,4 x 391 |
Document Size (Min) | A5 |
Document Size (Max) | A3 |
Memory (MB) | 1024 |
Grey Scale levels | 256 |
Dial Registration; rapid/speed dial | 1000 |
Broadcast Transmission (max. destinations) | 500 |
Finishing | |
Output Capacity Max. | 400 - 4000 |
Staple Capacity (sheets) Max. | 50 |
Saddle Stitch | OPT |
Off-set shifting | STD |
Hole punch | OPT |
